GWS-1002
TIGTOOL
11.5mm
40 beads/m
Sintered(Spring + Rubber)
High hardness granite
Related Products
1. Safty, high quarrying, no dust, low noise, low cost;
2. Good performance brings good size blocks without inner break;
3. Explore large dimension blocks;
4. Provide customized service.
| Bead specification | Number of beads | Connection | Cutting material | lines speed(m/s) | Cutting spead(m2/h) | Wire life(m2/m) |
| 11.5 | 40 | rubber/ rubber+spring | hard granite | 18-25 | 2-5 | 6-12 |
| mild hard granite | 22-26 | 4-8 | 7-15 | |||
| soft granite | 24-30 | 8-12 | 15-23 |
Attentions for the profiling diamond wire cutting on stationary machines:
1. Regular inspections of diamond wire self rotation and make adjustment in time.
2. Regular inspections of diamond wire abrasive to avoid cut-in-one-side problem happen. Once it happens, make the solution straight way.
3. Regular inspections the joint, as well as the beads of two sides, if they are abrasive badly, replaces them in time.
4. The cable tension of the stationary machines should be controlled within 250-300kg(φ 4-5mmcables).
5. Linear speed is changed according to the different hardness of stones.
Class 1-2 granite: 28-30m/s
Class 3-4 granite: 26-28m/s
Class 5 granite: 24-28m/s
Marble: 30-40m/s
Abrasive stone: 30-35m/s
6. For the new wire, when start to cut, its linear speed should be slower 2-3m/s than the standard mentioned above, it is good for sharpen.
7. Water supply is around 15-25L/min.
Packaging Details:
Carton box and wooden case are upon clients' request, customized prints are available!
Port:
Shanghai/Tianjin
Lead Time:
| Quantity(Pieces) | <1000 | >1000 |
| Est. Time(day) | 12 | To be negotiated |
1. A variety of styles and packaging for you to choose from.
2. Logo, style, size and packaging support customization.
3. Product damage or quality problems, We will double your compensation for your losses.
4. We can provide free sample for you test. From the order to delivery are strictly controlled.
Brief Introduction
TIGTOOL INC. is a comprehensive national high tech enterprise which is specializing in the R & D, manufacture, sale and trade of high grade diamond saw blade.
We specialize in producing Rotary Files, Diamond Saw Blades, Diamond Wire Saw, Diamond Core Drill Bits and other diamond tools.
In the future, we will adhere to the innovative business philosophy, adhere to the wholehearted service for customers, and provide customers with better diamond tools. We will also integrate various resources to fully utilize our technological advantages. Strive to make our company an international company with superior competitiveness and profound cultural heritage.
Technical Equipment
Our well equipped infrastructure is crucial in the growth and expansion of our business operations. The sophisticated and modern facilities help us to develop products effectively. Our infrastructure is spread over a large area and is segregated into manufacturing unit, quality division and warehousing unit.
Our manufacturing unit is equipped with special purpose machines and requisite tools & equipment. With the use of these machines, we are able to manufacture our products in bulk quantity and meet the requirements of our clients.
Quality Assurance
We make sure that wine appliance products render high quality standards. Our quality controllers regularly monitor entire stage of production process to ensure the perfect quality of our products. We adhere to latest technology and quality control procedure, which ensures quality standards and specifications. The company is able to offer first class quality and main products with full trace-ability by BV,SGS and ISO9001. Therefore, you could rest assure our perfect quality and service.
Q1: How is your quality?
A: We have a very seriously control system(ERP system). We guarantee the high performance of our products.
Q2: What is your warranty for your products?
A: For one year from shippment, if any problem happened to our goods, we will make prompt response, send replacement and take the shipping cost.
Q3: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q4: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q5: Can you provide OEM service?
A: Yes, we can produce the goods with clients' logo and brand.
Q6:How long you can reply to me when I send you an inquiry?
A: We promise to reply within 24 hours( including holidays) on receipt of your inquiry.
